12v 30 Amp CCTV Power Supply Open
Security & Surveillance Accessories
Type
Brand New
Condition
Other
Brand
Complies with rohs directive
ac input voltage range: 85-132/ 170-264vac selected by switch
input frequency: 47-63hz
inrush current: cold start, 20a/115v, 40a/230v
input leakage current: <0.7ma/230v
line regulation (full load): <± 0.5%
output voltage adj. range: ± 10%
output overload protection: 110-130% constant current, auto recovery
output over voltage protection: 115-150%
withstand voltage: i/p-o/p: 3.0kvac/1min; i/p-f/g: 1.5kvac/1min; o/p-f/g: 0.5kvac/1min
rise time: 50ms load (typical)
hold up time: 20ms load (typical)
operating temp.& humidity: -10°c to 50°c (14°f – 122°f), 20%-93%rh (non-condensing)
storage temp.& humidity: -20°c to 85°c (-4°f – 185°f), 20%-93%rh (non-condensing)
safety standards: gb4943, ul60950, en60950
emc standards: gb9254, en55022
cooling method: convection
