Technical parameters:
head &
needles head: 2 needles: 9
weight net weight: 450 gross weight: 470kg
size overall dimension: 1700*1050*1480mm package size: 1550*1300*1590mm
embroidery
area standard: 400*450mm
embroidery purpose suitable for cap, t-shirt, finished garments cloth embroidery
memory 20,000,000 stitches matched with 200 patterns
max. color change auto start and color change, 200 times color change setted
readable data compatible with designs of tajima(dst), barudan(dsb) and etc.
design input by u disk, usb and transmission from pc to control system
multi languages 12languages:chinese,english,french,russian,dutch,spanish,portuguese,turkish,german,arabic,thai, vietnamese
optional devices simple sequin device, simple cording device, eight in one device, boring device, simple taping device, laser position device
motor main motor: servo motor xy motor: stepper motor
x,y driving reinforced high speed linear guide rail
computer system 8 inch lcd touch screen
main part
