3 in 1 Oscilloscope Multimeter With Dual Channel 50mhz Bandwidth Rea
Brand New
Condition
Other
Brand
Other
Type
- 3.5 inch color screen handheld oscilloscope.
- automatic, normal, and single time trigger modes
- automatic measurement and scan.
- 20mv/div-10v/div vertical sensitivity.
- 8/10ns/div-20s/div horizontal scanning range.
- 20ppm time base accuracy.
- counts: 25000
- bandwidth: 50mhz
- sampling method: real time sampling
- channels: dual channel
- sampling rate: 280ms/s
- storage depth: 128kpts
- display screen: 3.5 inch ips color screen
- range: auto range
- dc current: 10a
- ac current: 10a
- dc voltage: 1000v
- ac voltage: 750v
- resistor: 250mω
- capacitance: 100mf
- frequency: 1mhz
- battery: li battery 2000mah x 1 (included)
- package list:
1 x oscilloscope multimeter
4 x test probes
1 x storage bag
1 x usb cable
22 x accessories
1 x manual
