Mastech My68 Auto Range Digital Multimeter With Capacitance,

+1

1

Brand New

Condition

Mastech

Brand

Digital Multimeter

Type

Capacitance, Current, Diodes, Duty Cycle, Frequency, Inductance, Resistance, Voltage

Measurement Functions

1000V

Voltage

500amps

Max Current

- auto power off - transistor hfe 0~1000 - diode open voltage 1.5v - data hold - auto and manual range - diode test - transistor - continuity test - ac/dc voltage - ac/dc current - resistance, capacitance and frequency - over range indication: lcd will display "ol". -low battery indication specifications: dc voltage: 400mv/4v/40v/400v(0.7%+2) 1000v(0.8%+2) ac voltage: 400mv(3%+3) 4v/40v/400v(0.8%+3) 750v(1.0%+3) dc current: 400a/4000ua/40ma/400ma(1.0%+5) 10a(1.5%+8) ac current: 400a/4000ua/40ma/400ma(1.5%+8) 10a(2.0%+10) resistance: 400/4k/40k/400k/4m(1.2%+2) 40m(2%+5) capacitance: 4nf/40nf/400nf/4f/40f/200f (4.0%+15) frequency: /10k/200khz 2.0% general characteristics: powewr supply: 1 * 6f229v) (not included) dimension: 91(l)*189(w)*31.5(h) mm weight: around 310g (not including battery) color: black & green package size:
