Hardware features
processor qualcomm atheros enterprise 560mhz cpu, mips 74kc
memory 64mb ddr2 ram, 8mb flash
interface 1 10/100mbps shielded ethernet port (lan0,passive poe in)
1 grounding terminal
1 reset button
power supply passive power over ethernet via lan0 (+4,5pins; -7,8pins)
voltage range: 16-27vdc
max. power consumption 10.5 watts max
note: when deployed using passive poe, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
dimensions ( w x d x h ) 224 x 79 x 60 mm
antenna built-in 13dbi 2x2 dual-polarized directional antenna
beam width: 45° (h-plane) / 30° (e-plane)
note: for more details, please refer to datasheet
protection 15kv esd protection
6kv lightning protection
enclosure outdoor asa stabilized plastic material
ipx5 waterproof cert
