Type
Compact pressurized flat panel solar water heater
Capacity
200L/300L
Model
GS-FP 2.0
Outer shell material
Galvanized steel with paint
Outer shell dimension (mm)
500/520/550/570
Inner tank material
Stainless steel SUS304 or SUS316
Inner tank dimension (mm)
420/450/460
Flat panel solar collector
Cover low iron tempered glass
Absorber Imported blue titanium coating, efficiency 95±2%
Dimension 2000x1000x80mm x 2 PCS
Solar frame
Galvanized steel (1.5mm)
Accessories
P/T valve/Electric Heater/Magnesium Rod/safety valve/Suction valve
Max Test Pressure
1.0Mpa/10 bar
Working Pressure
0.60 Mpa/6bar
