Model No.:SVC-15000
Brand Name: DROM Power
Packing:plywood case with pallet
Phase:Single Phase
Current Type:AC
Small in volume, affordable in price, easy to use, protect all your home appliance.
Capacity/Power
15KVA
Input Voltage Range
150V-250VAC
Output Voltage
220VAC±3%
Working Frequency
50/60Hz
Regulation Type
Servo motor type
Transformer Type
Digital display
Toroidal autotransformer
Transformer Winding Material
Al and Cu mixed
Response Time
≤1s
Efficiency
≥95%
Duty Cycle
Continuous
Adjusting Speed
>15V/s
Load Power Factor
0.8
Ambient Temperature
-10°C to +40°C
Altitude
≤1000m
Relative Humidity
≤90%
Dielectric Strength
No damage at 1500V for 1 minute
Insulation Resistance
≥5MΩ
Waveform Distortion
Nil
Acoustic Noise
≤50dBA
Display
Analogue Meter
Protection
Input Circuit Breaker, Over Voltage (L-N, 248±4V), Under Voltage (L-N, 180±4V), Overload, Short Circuit, etc
Installation
Indoor and floor mounted
Protection Degree
IP20
