-cells per unit 6
-voltage per unit 12
-nominal capacity 80ah-rate to 1.80v per cell °c
-weight approx. 21.5 kg (tolerance±3.0%)
-max. discharge current 800a (5 sec)
-internal resistance approx. 6.0 mω
-terminal f5(m8)/f11(m6)
-max. charging current 24.0a
-container material a.b.s. ul94-hb, ul94-v0 optional.
operating temperature range
discharge: -20°c~60°c
charge: 0°c~50°c
storage: -20°c~60°c
normal operating temperature range 25°c±5°c
standby use voltage 13.6 v~13.8 v @ 25°c
cycle use voltage
-self discharge
ritar valve regulated lead acid (vrla) batteries can
be stored for up to 6 months at 25°c and then recharging
is recommended. monthly self-discharge ratio is less
than 3% at 25°c.please charge batteries before using.
design life 12 years (float charging)
