Ac output power (rated): 16,000 w (16 kw)
max ac apparent power: 17,600 va
rated ac current: 69.6 a
input dc power max: 20,800 w
max dc input voltage: 500 v
mppt voltage range: 150 v – 425 v
start-up voltage: 125 v
efficiency (max): 97.6 %
euro efficiency: 96.5 %
battery voltage range: 40 v – 60 v
max charge/discharge current: 290 a
ingress protection: ip65
operating temperature: –40 °c to +60 °c (derating past ~45 °c)
dimensions (w × h × d): 464 × 763 × 282 mm (excluding connectors)
weight: ~ 52 kg
warranty: 5 years (option to extend to 10 years)
