Nominal Capacity: 16 kWh (with a Usable Energy capacity of 15.3 kWh).
Battery Capacity Rating: 314 Ah.
Nominal Voltage: 51.2V.
Current Limits: Maximum continuous charge current of 150A and maximum continuous discharge current of 200A.
Environmental Protections: IP20 protection rating, utilizing natural convection cooling.
Operating Temperature Limits: Charging window spans 0°C to 55°C, while the discharging range spans -20°C to 60°C.
Lifespan & Scalability: Designed for a cycle life of 6,000+ cycles at 80% Depth of Discharge (DOD). The integrated Battery Management System (BMS) supports communication via CAN / RS485 and allows stacking of up to 48 battery packs in parallel to scale total power storage.
