Meanray Magnetic Starter Motor Control Switch

+1

Meanray

Brand

Phase failure

Type

Brand New

Condition

Store address

Nairobi • Nairobi Central

Signage Arcade

Near Simba coach booking office along duruma road

Closed now

• Mon - Sat, 09:00-17:00

• Three-Phase Power Compatibility: The diagram outlines power connections for L1, L2, and L3 input phases feeding into a main motor configuration through integrated power contacts. • Electromechanical Contactor Control (KM): It includes a dedicated terminal loop for controlling an electromagnetic KM coil. This coil acts as the internal switch that mechanically pulls power contacts shut to safely supply high-voltage current to the motor. • Dual Push-Button Operation (SB1 & SB2): The control circuit layout supports basic industrial control configurations via remote or local buttons: • SB1: Wired as a normally closed (NC) Stop / Off button. • SB2: Wired as a normally open (NO) Start / On button
