-cells per unit 6
-voltage per unit 12
-capacity 200ah-rate to 1.75v per cell °c
-weight approx. 59.0 kg (tolerance±3.0%)
-max. discharge current 2000a (5 sec)
-internal resistance approx. 3.5 mω
-terminal f16(m8)/f10(m8)
-max. charging current 60.0 a
-container material a.b.s. ul94-hb, -ul94-v0 optional.
operating temperature range
-discharge: -20°c~60°c
-charge: 0°c~50°c
-storage: -20°c~60°c
-normal operating temperature range 25°c±5°c
-float charging voltage 13.6 v~13.8 v @ 25°c
14.6 v~14.8 v @ 25°c cycle use voltage
-self discharge
ritar valve regulated lead acid (vrla) batteries can
be stored for up to 6 months at 25°c and then recharging
is recommended. monthly self-discharge ratio is less
than 3% at 25°c.please charged batteries
