✓Rated voltage 51.2v
✓Rated capacity 314ah
✓Battery power 16.07kwh
✓ Battery type LiFePO4 cycling lifespan(80% dod,0.5c,25°c)8000 cycles lifetime 20 years >l
✓Max. parallel capacity 16 units
✓ Max. charging voltage 57.6v
✓ Over discharging voltage 44.8v
✓ Max. charging current 200a
✓ Peak charging current 220a (3s)
✓ Max. discharging current 200a
✓ Peak discharging current 220a (3s)
✓ Breaker Current 240a
~Weight 114kg(251.3lb), Dimension(l*w*h)1075*460*271mm (3.53*1.51*0.89ft)
~Communication CAN/ RS485 /USB / Wi-Fi / Bluetooth
✓ Cooling method neutral cooling
✓protection grade IP65 intelligence
✓supports wall or floor mounting •
✓easy to install &;user friendly
✓compatible with many brands of inverter protocols
✓up to 16 units in parallel, expand to 256kwh
✓high quality lithium iron phosphate cells
✓ip65 protection degree
