Key specifications & features
capacity: 6.2 kva / 6.2 kw (6200w) rated power
voltage system: 48v dc
solar charging: 120a or 160a built-in mppt controller
max pv input power: 6500w
max pv input voltage: 500v dc
mppt range: 60vdc - 450vdc
surge power: 12400va
output waveform: pure sine wave
max ac charging current: 100a
battery voltage range: 40vdc - 63vdc
efficiency: 97% max
features: dual output for smart load management, anti-dust kit, wifi for monitoring.
solarmall.ng
solarmall.ng
+8
operating modes
on/off grid: capable of feeding power back to the grid.
battery independent: can operate without a battery connected.
battery type: compatible with lithium and lead-acid, with automatic lithium activation.
scribd
scribd
+3
physical dimensions
weight: approximately 17 kg
dimensions: 500mm x 390mm x
