Working range* up to 30 m
Working range with receiver* up to 120 m
Accuracy* +/- 0.3 mm/m*/** (*for the four horizontal intersection points ; **plus use-dependent deviation)
Laser diode Line: 630 – 650 nm, < 10mW
Operating temperature -10 – 40 °C
Storage temperature -20 – 70 °C
Laser class 2
Working range without receiver up to 30 m
Self-levelling range ± 4°
Levelling time 4 s
Dust and splash protection IP 54
Power supply 4 x 1.5 V LR6 (AA)
Operating time (max.) 4 h in 3-line mode
Tripod thread 1/4′′, 5/8′′
Weight, approx. 0.82 kg
Colour of laser line green
Projection 3 x 360° line
Compatible laser receivers LR 6 + 7
